Temperature And Speed Monitoring On Google Sheet-Based Motorcycle Discs

Authors

  • Akbar Ari Wibowo Universitas Muhammadiyah Sidoarjo
  • Syamsudduha Syahrorini Universitas Muhammadiyah Sidoarjo
  • Arief Wisaksono Universitas Muhammadiyah Sidoarjo

DOI:

10.47709/cnahpc.v5i2.2880

Keywords:

Monitoring, overheat, NodeMCU ESP8266, Sensor MLX90614, Sensor E18-D80NK, Google sheet

Dimension Badge Record



Abstract

The braking system for motor vehicles is very important which serves to slow down speed. So that the braking system is one that must be considered for driving safety. There are two types of braking systems on motorcycles based on the mechanism, namely braking using discs and drums. One of the causes of road accidents is because the brakes overheat so that failure of the braking system results in brake failure. Therefore, this research is about the design of temperature and speed monitoring on motorcycle brake discs based on google sheets. Which uses MLX90614 sensor as a temperature sensor and E18-D80NK sensor as a speed sensor and NodeMCU ESP8266 as a microcontroller. Both sensors are programmed to provide information so that the brake temperature does not overheat and turn on the buzzer when the temperature and speed reach / exceed predetermined values. The buzzer will turn on when the temperature on the disc brakes reaches ?65°C and when the speed reaches 120rpm.

Downloads

Download data is not yet available.
Google Scholar Cite Analysis
Abstract viewed = 126 times

References

Anjasmara, M. F., Laras, Y. B., Azrie, W. H., Wardiana, L. P., & Setijo Budi, S. (2016). Rancang Bangun Sistem Peringatan Suhu Pengereman Berbasis Mikrokontroller ATmega 16. 1–7. https://doi.org/10.5614/sniko.2015.1

Azdhar Baruddin, L. O. M. A. (2020). Analisis Pengaruh Kecepatan Terhadap Jarak Dan Waktu Pengereman Pada Mobil Hybrid Urban Kmhe 2018. Jurnal Teknik Mesin, 9(3), 195. https://doi.org/10.22441/jtm.v9i3.4998

Eko, C. (2014). Bab I Pendahuluan?. Universitas Andalas, 10(3), 1.

Harsoyo, I. T., Nugroho, A. K., & Nuriman, N. (2019). Rancang Bangun Tachometer Digital Berbasis Arduino Dilengkapi Charging Dan Mode Penyimpan Data. Elektrika, 11(2), 6. https://doi.org/10.26623/elektrika.v11i2.1692

Hutauruk, J. (2019). Rancang Bangun Sistem Kendali Pintu Garasi Menggunakan Android Berbasis Arduino Uno. Angewandte Chemie International Edition, 6(11), 951–952., 64.

Journal, R. T. (2023). Vol. 6 No.1 Januari 2023 Rang Teknik Journal. 6(1), 100–106.

Kusuma, H. A., Yunianto, A. H., Suhendra, T., Egistian, F., & Siagian, R. B. . (2022). Pemrograman Dasar Internet of Things Menggunakan ESP8266 Tonny Suhendra (Issue September). https://www.researchgate.net/publication/363429895

M. Iman Wahyudi, & Rifki Abdul Aziz. (2022). Keran Air Wudhu Otomatis Menggunakan Sensor Infrared Sebagai Upaya Meminimalisasi Pemborosan Air. Journal of Applied Computer Science and Technology, 3(1), 151–156. https://doi.org/10.52158/jacost.v3i1.296

Nugraha, A. W., Prasetyo, I., & Taryudi. (2021). Alat Monitoring Detak Jantung, Kadar Oksigen Dalam Darah Dan Suhu Tubuh Berbasis Internet of Things. Autocracy: Jurnal Otomasi, Kendali, Dan Aplikasi Industri, 7(1), 42–47. https://doi.org/10.21009/autocracy.071.7

Pada, P., Cakram, R. E. M., & Arduino, B. (2022). Skripsi rancang bangun alat pendeteksi suhu pengereman pada rem cakram berbasis arduino.

Prameswari, D., & Yohanes, Y. (2019). Analisa Sistem Pengereman Pada Mobil Multiguna Pedesaan. Jurnal Teknik ITS, 8(1). https://doi.org/10.12962/j23373539.v8i1.42494

Rashid, A. (2014). Overview of disc brakes and related phenomena - A review. International Journal of Vehicle Noise and Vibration, 10(4), 257–301. https://doi.org/10.1504/IJVNV.2014.065634

Saragih, E. W., Lubis, M. R., Wanto, A., Solikhun, S., & Jalaluddin, J. (2021). Rancang Bangun Sistem Rem Otomatis pada Kendaraan Menggunakan Sensor Ultrasonik. Jurnal Penelitian Inovatif, 1(2), 85–94. https://doi.org/10.54082/jupin.11

Sasmoko, D. (2021). Arduino dan Sensor (Vol. 1).

Sasmoko, D., Nur Afifah, & Iman Saufik. (2021). Pengukura Suhu dengan Ir MLX90614 dan NoDeMCU dan Membandingkan dengan Ds18B20 untuk pencegahan Covid 19. Elkom?: Jurnal Elektronika Dan Komputer, 14(2), 256–260. https://doi.org/10.51903/elkom.v14i2.523

Septriana, H. W., Dwi Haryadi, G., & Ariyanto, M. (2017). Pembuatan dan Pengujian Alat Pengukur Temperatur pada Rem Tromol Kendaraan Roda Dua dengan Remote Measuring System. Jurnal Teknik Mesin S-1, 5(1), 66.

Sunarya, U., & Novianti, A. (2019). SISTEM PENDETEKSI KAMPAS SEPEDA MOTOR BERBASIS IoT ( SYSTEM DETECTION of CANVAS MOTORCYCLE BASED on IoT ). 5(1), 409–420.

Susilo, D., & Maghfiroh, A. M. (2022). Sensor Pengukur Kecepatan Putaran Motor Berbasis Mikrokontroller AT-Mega 8535. ELECTRA?: Electrical Engineering Articles, 3(01), 43. https://doi.org/10.25273/electra.v3i01.13983

Trinovat, F. (2018). Rancang Bangun Sistem Pengereman Otomatis Dan Blind Spot Warning Pada Sepeda Motor. UIN Alauddin Makassar, 3–18.

Zaini aryatama, F. (2022). Analisis Penyebab Kecelakaan Lalu Lintas Di Jalan Empunala Kota Mojokerto. Jurnal Teknik Sipil?: Rancang Bangun, 8(2), 150–155. https://doi.org/10.33506/rb.v8i2.1805

Downloads

ARTICLE Published HISTORY

Submitted Date: 2023-09-22
Accepted Date: 2023-09-22
Published Date: 2023-09-26

How to Cite

Wibowo, A. A. ., Syahrorini, S. ., & Wisaksono, A. . (2023). Temperature And Speed Monitoring On Google Sheet-Based Motorcycle Discs. Journal of Computer Networks, Architecture and High Performance Computing, 5(2), 735-742. https://doi.org/10.47709/cnahpc.v5i2.2880
